Frequency Transducer, 40-60Hz/45-55Hz/55-65Hz/0-100Hz

Write a review

$175.54

Reliable frequency transducer, the range is 40-60Hz/45-55Hz/55-65Hz/0-100Hz. The working environment temperature of the frequency transducer is 0~50℃, the working environment humidity is <80% relative humidity, and the compressive strength is AC2Kvrms/min. It has a wide range of applications and is durable.

Range *
Accuracy *
Output Channel *
Output Signal *
Fine-tuning Knob *
Transducer Power *

SKU: ATO-PT-F

Qty:

30-day Returns

Free Shipping

Delivery date: 6-12 days

Overview

The output ripple of the frequency transducer is ≤ 0.5% RO peak. The shell material of the frequency transducer is ABS fireproof material, and the compressive strength is AC2Kvrms/min. It is installed using a 35mm standard rail or fixed on a cabinet.

Specification

Model	ATO-PT-HDB-F
Range	40-60Hz, 45-55Hz, 55-65Hz, 0-100Hz, customization (optional)
Allow Overload	Voltage×1.2 times the nominal value lasts
Accuracy	0.2, 0.5 (optional)
Response Time	≤400ms
Output Channel	1 channel, 2 channels, 3 channels (optional)
Output Voltage	0-10V, 0-5V, 1-5V (load resistance = input voltage/10mADC)
Output Current	0-1mA, 0-10mA, 0-20mA, 4-20mA (Load resistance=10VDC/output current)
Other Output	RS485, customization
Output Ripple	≤0.5% RO peak
Work Environment Temperature and Humidity	0~50℃/less than 80% relative humidity (no condensing)
Storage Conditions Temperature and Humidity	-20~70℃/less than 70% relative humidity (no condensation)
Aux.power Supply	DC12V, DC24V, AC220V, DC220V, AC110V, DC110V, 2-wire circuit power supply, internally powered (optional)
Isolation	Input/output/power supply/shell
Power Consumption	DC about 3W, AC about 4VA
Material of Shell	ABS fireproof material
Weight	About 300 grams
Compressive Strength	AC2kVrms/min
Insulation Resistance	>100MΩ at DC500V
Dimension	120 (L) × 55 (W) × 75 (H) mm
Installation Method	35mm standard guide rail or fixed on the cabinet

Dimension (Unit: mm)

Dimension of frequency power transducer

Calibration Fine Tuning

Frequency power transducer calibration fine tuning

PWR: Power indicator
SPAN: Calibration full scale potentiometer
ZERO: Zero potentiometer

Wiring

Tips: How to choose the right power transducer?

Determine the type of power to be measured: Select a transducer that is compatible with the type of power in your system, and make sure the sensor matches your electrical system configuration.
Determine electrical parameters: Select a transducer with voltage input that matches your system (e.g., 0-100V, 0-600V, etc.), and choose a model that supports the expected current load, either directly or through a current transformer (CT).
Consider accuracy and response time: High accuracy is critical for precise power monitoring in industrial and commercial applications. Fast response time is critical for dynamic load monitoring.
Environmental and mounting considerations: Mounting types include DIN rail, panel, or enclosure mounting. Make sure the operating temperature and humidity of the power transducer selected can withstand the environmental conditions.
